型号：PMVF
排气量：16~68.7m3/min
排气压力：0.45~1Mpa
电机功率：75~250kw
重量：3300~9260kg
JN二级压缩系列永磁变频空压机参数
| 产品型号 | 排气压力（Mpa) | 排气量（m3/min） | 电机功率(KW) | 排气接口 | 噪声dB(A) | 重量(KG) | 外形尺寸(MM) |
| PMVF75-18/6-Ⅱ | 0.6 | 18 | 75 | DN65 | 73 | 3300 | 3110x1780x2020 |
| PMVF75-18/7-Ⅱ | 0.7 | 18 | |||||
| PMVF75-16/8-Ⅱ | 0.8 | 16 | |||||
| PMVF90-23/6-Ⅱ | 0.6 | 23 | 90 | 3600 | 3110x1780x2020 | ||
| PMVF90-21/7-Ⅱ | 0.7 | 21 | |||||
| PMVF90-20/8-Ⅱ | 0.8 | 19.5 | |||||
| PMVF90-18/10-Ⅱ | 1 | 16.5 | |||||
| PMVF110-26/6-Ⅱ | 0.6 | 26 | 110 | 74 | 4450 | 3100x1890x2060 | |
| PMVF110-26/7-Ⅱ | 0.7 | 26 | |||||
| PMVF110-24/8-Ⅱ | 0.8 | 24 | |||||
| PMVF110-20/10-Ⅱ | 1 | 19.5 | |||||
| PMVF132-34/6-Ⅱ | 0.6 | 34 | 132 | DN80 | 75 | 5100 | 3440x1930x2260 |
| PMVF132-32/7-Ⅱ | 0.7 | 32 | |||||
| PMVF132-28/8-Ⅱ | 0.8 | 28 | DN65 | 4550 | 3100x1890x2060 | ||
| PMVF132-24/10-Ⅱ | 1 | 24 | |||||
| PMVF160-40/6-Ⅱ | 0.6 | 40 | 160 | DN80 | 76 | 6100 | 3770x2060x2280 |
| PMVF160-38/7-Ⅱ | 0.7 | 38 | |||||
| PMVF160-33/8-Ⅱ | 0.8 | 33 | |||||
| PMVF160-31/10-Ⅱ | 1 | 31 | |||||
| PMVF185-44/6-Ⅱ | 0.6 | 44 | 185 | DN100 | 77 | 6300 | 3770x2060x2280 |
| PMVF185-42/7-Ⅱ | 0.7 | 42 | DN80 | 6200 | |||
| PMVF185-38/8-Ⅱ | 0.8 | 38 | |||||
| PMVF185-34/10-Ⅱ | 1 | 34 | |||||
| PMVF200-48/6-Ⅱ | 0.6 | 48 | 200 | DN100 | 6450 | 3770x2060x2280 | |
| PMVF200-46/7-Ⅱ | 0.7 | 46 | |||||
| PMVF200-41/8-Ⅱ | 0.8 | 41 | DN80 | 6300 | 3660x2060x2280 | ||
| PMVF200-40/10-Ⅱ | 1 | 40 | |||||
| PMVF220-55/6-Ⅱ | 0.6 | 55 | 220 | DN100 | 79 | 8920 | 4160x2260x2350 |
| PMVF220-53/7-Ⅱ | 0.7 | 53 | |||||
| PMVF220-47/8-Ⅱ | 0.8 | 47 | |||||
| PMVF220-43/10-Ⅱ | 1 | 43 | |||||
| PMVF250-60/6-Ⅱ | 0.6 | 60 | 250 | DN125 | 9420 | 4260x2410x2350 | |
| PMVF250-57/7-Ⅱ | 0.7 | 57 | |||||
| PMVF250-54/8-Ⅱ | 0.8 | 54 | DN100 | 9220 | 4160x2260x2350 | ||
| PMVF250-47/10-Ⅱ | 1 | 47 | |||||
| PMVF75-21/4.5-II | 0.45 | 21.2 | 75 | DN80 | 72 | 3300 | 3160×1840×2020 |
| PMVF90-26/4.5-II | 0.45 | 25.8 | 90 | DN80 | 72 | 3740 | 3160×1840×2020 |
| PMVF110-32/4.5-II | 0.45 | 32.4 | 110 | DN100 | 73 | 5100 | 3560×2010×2100 |
| PMVF132-39/4.5-II | 0.45 | 39.2 | 132 | DN100 | 73 | 5200 | 3560×2010×2100 |
| PMVF160-45/4.5-II | 0.45 | 44.8 | 160 | DN100 | 75 | 5900 | 3660X2060X2170 |
| PMVF185-49/4.5-II | 0.45 | 48.6 | 185 | DN100 | 76 | 6100 | 3660X2060X2170 |
| PMVF200-54/4.5-II | 0.45 | 54.4 | 200 | DN125 | 76 | 8000 | 3960×2260×2350 |
| PMVF220-61/4.5-II | 0.45 | 60.7 | 220 | DN150 | 78 | 9000 | 4260×2410×2350 |
| PMVF250-69/4.5-II | 0.45 | 68.7 | 250 | DN150 | 78 | 9260 | 4260×2410×2350 |
